ABOUT OUR E-BIKE
When it comes to commuting via bike, too much riding will leave us exhausted and sweaty. So we designed Qualeibike. Firstly a great bike, then a pedal assistant e-bike, and to top it off, we also added a cruise control system.
Folding Frame
Aluminum Alloy Grade 6061 frame and front fork, totally new design, passed all vibration tests, light but strong enough to hold up to 220 lbs. It can also be folded within 3 steps so it doesn’t occupy too much of your room or to easily fit in your trunk.
Motor
Customized 250W high speed geared brushless motor, less than 5 lbs but with 40 Nm torque, so you can go uphill over 18°. It’s so powerful that you can tackle hills without breaking much of a sweat. With a built-in clutch, you’ll never feel any magnetic resistance when riding without any power—it’s a pure, comfortable bike.
Battery
To make Qualiebike neat and unique, we chose a seat-post lithium battery as our power system. At first glance, most people won’t recognize it’s an e-bike. And BMS system is also important. It keeps your battery safe from over-charging, over the outlet and overheating. Also, BMS manages all the cells to work more efficiently to offer you a longer range. The seat-post battery is removable so you can either charge in the bike or separately in your room.
Disc Brake
Front and rear disc break keep you safe from any emergency with a break distance within 3 meters. Also, e-bike lever is another safety feature on this bike shutting down the power system right away if you apply the breaks.
PAS Riding System
The multi-function LCD display, 12 points sensor, and FOC controller together combine the PAS system. You can either ride at pedals mode, in cruise control mode without pedaling or pure bike mode if you need. The sensor could detect every intention precisely. Once you ride a Qualiebike, you will fall in love with it.
SPECIFICATIONS:
- Battery Capacity: 36V 7Ah (Samsung)
- Battery Type: Lithium-ion
- Brake: 160mm disc brakes(F/R)
- Brake Lever: Al-Alloy e-bike lever
- Chain: KMC
- Chainwheel: Prowheel 52T
- Controller: Kunteng sine wave FOC
- Display: Multifunctional LCD
- Flywheel: Qualisports 14T
- Frame: 16-inch 6061 Al-Alloy
- Front Fork: 6061 Al-Alloy
- Grips: EVA
- Handlebars: Promax
- Motor: 250W brushless geared DC motor
- Motor Efficiency: ≥80%
- Mudguards: Steel
- Net Weight: 30 lbs
- Noise: ≤62db(A)
- Overcurrent: 12±1A Kwh ≤1.2Kw.h
- Pedal: folding pedals
- Range: PAS >30 Miles
- Rated Output Power: 250W
- Rated RPM: 300r/min
- Rated Voltage: 36V F&R
- Rear Hub: Sigma Al-Alloy
- Ridesystem: 5-level PAS + cruise
- Rim: 16-inch Al-Alloy 13G36
- Saddle: KNUS
- Standard Load: 220 lbs
- Tire: Kenda 16*2.125
- Wheelbase: 930mm
