SUR-RON STORM BEE MX and Homologated Version Revealed!

SUR-RON revealed new STORM BEE dirt-bike lineup on CIMA 2019. Homologated and MX versions of STORM BEE were shown together with the popular Light Bee model.

We were first to post the Spy-shots from the testing dirt-bike track together with Video of this upcoming model ! You are going to love what we have for you right now!

SUR-RON STORM BEE MX and Homologated Electric Motorcycles

Unlike the Light Bee model, STORM BEE is aiming to satisfy all the hard-core dirt-bike riders. When Light-bee came out, electric vehicle community hungry for light electric motorcycle with huge torque that got us crazy for this model, but the Alta motors owners of Redshift electric motorcycle were not impressed.

SUR-RON-STORM-BEE-HOMOLOGATED-ELECTRIC-electric-MOTORCYCLE
STORM BEE homologated version

SUR-RON team got back to the drawing board and decided to push the boundaries once again adding swooping 520 NM to the rear wheel while pushing 22 Kw of power from 4.6 Kw/h battery ( SONY VTC 6 cells )! 150V capable Sine Wave Controller ( using only 96v ) and a BLDC motor with 8000r/min will give this beast 110 Km/h speed. Equiped with ASR+BERS you will feel confident riding this bike on corners. STORM bee maintained the same climbing angle of 45 degrees like its younger brother Light Bee.

sur-ron-storm-bee-96v-48-ah-battery
Sur-ron STORM BEE 96v 48 ah battery with SONY VTC 6 CELLS

SUR-RON-STORM-BEE-MX-HOMOLOGATED-ELECTRIC-electric-MOTORCYCLE The STORM BEE design is beautiful and we are sure you are going to love it, but what about the electric motor drive-train and detailed specifications?

We can only guess that SUR-RON used one of their patented power systems described in details here together with new electric motor mask described here.

Confrimed SUR-RON STORM BEE Specifications

SUR-RON-STORM-BEE

SUR-RON-STORM-BEE HOMOLOGATED

STORM BEE HOMOLOGATED VERSION

MODEL STORM BEE (Road Legal)
Vehicle Dimension 2120mm×810mm×1430mm
Min. Ground Clearance 300mm
Wheelbase 1435mm
Seat Height 900mm
Net Weight (Include Battery) 126KG
Stroke of Fr. Suspension 290mm
Stroke of Rr. Suspension/Wheel 115/290mm
Motor Type High Speed Brushless DC Air-Cooled Mid-Drive Motor
Controller Type 150V Sine Wave Controller
Max. Motor Rotation Speed 8000r/min
Peak Motor Output Power 22.5KW
Max. Torque of Driving Wheel 520N.m
Climbility 45°
Top Speed 110KM/H
Range(@50KM/H) ≥100Km
Battery Type 96V/48Ah High-Rate Ternary Lithium Battery (With SONY VTC6 Cells)
Frame Material & Processing Method Forged Aluminum Alloy Frame
Wheel Size Fr.: 19×2.50; Rr.: 17×3.75
Tire Type & Size All Terrain Tire, Fr.: 110/80-19; Rr.: 140/70-17
Fr. Suspension Adjustable Up-Side-Down Absorber (φ47mm, Stroke 290mm)
Rr. Suspension Adjustable Mono Air Absorber
ABS+ASR+BERS ABS+ASR+BERS
Light Type All LED Lights
Charging Time 3h
USB Interface USB-2.1A Single Socket
Dashboard LCD
GPS Position Function APP Connection Function
Re-Gen Function Under Sport Mode with Re-Gen
CAN Communication Function Yes
Fault Diagnosis Function Yes
Rear View Mirror Yes
Turning Light LED
Steering Lock Yes

STORM BEE MX VERSION

SUR-RON-STORM-BEE MX
STORM-BEE MX VERSION
MODEL STORM BEE (MX)
Vehicle Dimension 2120mm×810mm×1430mm
Min. Ground Clearance 320mm
Wheelbase 1435mm
Seat Height 920mm
Net Weight (Include Battery) 118KG
Stroke of Fr. Suspension 290mm
Stroke of Rr. Suspension/Wheel 115/290mm
Motor Type High Speed Brushless DC Air-Cooled Mid-Drive Motor
Controller Type 150V Sine Wave Controller
Max. Motor Rotation Speed 8000r/min
Peak Motor Output Power 22.5KW
Max. Torque of Driving Wheel 520N.m
Climbility 45°
Top Speed 110KM/H
Range(@50KM/H) ≥100Km
Battery Type 96V/48Ah High-Rate Ternary Lithium Battery (With SONY VTC6 Cells)
Frame Material & Processing Method Forged Aluminum Alloy Frame
Wheel Size Fr.: 21×1.60; Rr.: 18×2.15
Tire Type & Size Off-Road Tire, Fr.: 80/100-21; Rr.:100/90-18
Fr. Suspension Adjustable Up-Side-Down Absorber (φ47mm, Stroke 290mm)
Rr. Suspension Adjustable Mono Air Absorber
ABS+ASR+BERS ASR+BERS
Light Type No
Charging Time 3h
USB Interface USB-2.1A Single Socket
Dashboard LCD
GPS Position Function No
Re-Gen Function Under Sport Mode with Re-Gen
CAN Communication Function Yes
Fault Diagnosis Function Yes
Rear View Mirror No
Turning Light No
Steering Lock No

More Sur-Ron STORM BEE details

strom-bee-display

SUR-RON ON CIMA 2019.
SUR-RON ON CIMA 2019.

For more details or business inquiry, please contact SURRON with email
